WGSL: Three Ways to Declare Pure Values

Table of Contents

Introduction

The WebGPU Shading Language (or WGSL) has four ways to declare named values: var, const, override, and let.

A var declares a variable: a name for storage holding a value. For this post we’ll forget about memory for now — see what I did there? — and talk about the others.

So what’s up with the other three?

Giving names to pure values

Each of const, override, or let gives a name to a value like a number, vector, array, or structure.

Once created, the value does not change. This is great because when reading code, there are fewer moving parts to keep track of.

💡 The objects created by const, override, and let are simpler than variables because you can reason about them while knowing much less about how computers work. To fully understand variables, you need to understand how memory is structured, with allocations and addresses, and how different parts of the system can — sometimes concurrently — read from and write to that memory. That gets pretty deep pretty fast.

So why are there three of them?

There are three kinds of (pure) value declarations because three distinct phases in the life of a WGSL program when an expression can be evaluated.

They are:

1. Shader creation time: during the createShaderModule API call.
2. Pipeline creation time: during createComputePipeline, createRenderPipeline, and their variants.
3. Shader execution.

Take a look at the diagram. It shows the key interactions between a WebGPU Application and the WebGPU implementation (e.g. your browser).

I’ve abstracted away the first part, where you get the GPUAdapter, then the GPUDevice from the adapter, and the middle parts where you create resources, bind group layouts, and record the commands to be executed on the GPU.

The parts shown in more detail are:

1. Shader creation time.
   • A shader is created when the application calls device.createShaderModule, providing a GPUShaderModuleDescriptor which itself contains the WGSL source code.
   • This is when all const-expressions are evaluated.
     • The values of const-expressions depend only on the WGSL source code.
     • They can use literals (like 3.14), arithmetic and logical operators, calls to built-in functions with the @const attribute, and const-declared values.
   • This is also when the values for const-declarations are set once and for all.
2. Pipeline creation time. Let’s take the compute pipeline case; the render pipeline case is similar.
   • A compute pipeline is created when the application calls device.createComputePipeline (or its async variant), providing a GPUComputePipelineDescriptor, which in turn has a GPUProgrammableStage.
   • The GPUProgrammableStage holds the shader module created in step 1.
   • This is when all override-expressions are evaluated.
     • They can use const-expressions (including const-declared values), arithmetic and logical operators, calls to built-in functions with the @const attribute, and override-declared values.
   • This is also when the values for override-declarations are set once and for all.
   • 💡 Why didn’t we evaluate override expressions earlier? This is where it gets interesting. In addition to the shader module, the GPUProgrammableStage also holds a constants dictionary mapping names and ids to scalar values. Which matters because…
   • When evaluating override-expressions, the value of an override declaration can be set by an entry the constants dictionary instead of taking the value of its initializer:
     • If constants has an entry (key,X), and key is the identifier for an override, then the value for that override will be X.
     • Alternately, if an override declaration has an @id(E) attribute, and key is the string for the (decimal) value of E, then the value for that override will be X.
     • If an override declaration has no such matching entry, then it takes the value computed for its initializer expression.
   • Corner cases include:
     • An override controlled in this way must be of scalar type.
     • The X value given on the API side is interpreted as a double-precision float. The value must be convertible to the override’s type.
     • If an override has no initializer, and isn’t matched this way, then pipeline creation fails.
3. Shader execution.
   • This happens when the shader is a stage in a pipeline, a command to execute the pipeline is written to a command buffer, that command buffer is submitted to a queue, and finally the enqueued command eventually is scheduled to run on the GPU.
   • The shader executes starting at the designated entry point function, and continues executing until that entry point finishes.
   • Each time let-declaration is reached, it takes the value of its initializer expression.
   • Any expression which hasn’t already been evaluated in steps 1 or 2 above is called a runtime expression, and is evaluated when execution reaches it.
   • Runtime-expressions can depend on things that are only known at shader execution time, some of which may change during shader execution, including the values stored in variables, pipeline inputs, and the result of executing functions.

💡 The initializer to a let declaration can also be a const-expression or an override-expression, depending on which functions and declarations it mentions.

Here’s an example compute shader that copies one array to another. It demonstrates const, override and runtime expressions. Each invocation copies up to block_size adjacent elements from the source to the destination.

const block_size = 8;
override wg_size = 16;

@group(0) @binding(0) var<storage> source: array<u32>;
@group(0) @binding(1) var<storage,read_write> dest: array<u32>;

@compute @workgroup_size(wg_size)
fn main(@builtin(global_invocation_id) gid: vec3u) {
  let num_elem = min(arrayLength(&source), arrayLength(&dest));
  for (var i = 0u; i < block_size; i++) {
    let my_idx = gid.x * block_size + i;
    if (my_idx < num_elem) {
      dest[my_idx] = source[my_idx];
    }
  }
}

(I haven’t tried the code. I’ve just compiled it.)

In summary the key differences between the ways of declaring pure values are:

• const-declaration initializers are const-expressions: their values are finalized at shader-creation time, only using information in the WGSL source code.
• override-declarations are initialized with override-expressions: their values are finalized at pipeline-creation time, and can be overridden by a constants dictionary provided at that time.
• let-declarations are initialized with runtime-expresisons: their values are computed each time execution reaches them, and can use data that dynamically changes during runtime.

A few more things

Numeric const-expressions can be high precision

Const-expressions are designed to be evaluated on the CPU, once, when the shader is first created. CPUs generally support high precision numeric types, and WGSL lets you use those types when computing const-expressions.

WGSL calls these types AbstractInt and AbstractFloat, and they each have at least 64 bits of precision each. For example, a number like 123456 is an AbstractInt, and 1.3e10 is an AbstractFloat.

In this code snippet, all the expressions are const-expressions, and are evaluated with 64 bit precision.

     const distance_to_sun_m = 149597870700;
     const year_in_s = 365.25 * 24 * 3600;
     const pi = 3.141592653589793238462643;
     const velocity_of_earth_m_per_s = 2 * pi * distance_to_sun_in_meters / year_in_s;

Edge cases before runtime are errors

An error is generated when a const-expression or override exception overflows, or produces an infinity or NaN.

In this code snippet, both lines are errors.

     const oops = 1.0 / 0.0;
     const oops_nan = 0.0 / 0.0;

Why? Two reasons:

• GPUs often take shortcuts with floating point math. They generally don’t implement full IEEE 754 floating point rules. They won’t behave nicely in overflow and other edge cases, and they definitely won’t signal exceptions. So relying on specific behaviour in those cases will be non-portable, and portability is important for a web standard. So WGSL takes the attitude that producing those edge cases is a problem, a defect. Expressions evaluated before runtime (const and override) are computed on the CPU, and implementations can (mostly) reliably detect the edge cases at that time. So the implementation is required to generate an error.
• Room for expansion. Someday we might want to use more than 64 bit precision for AbstractInt and AbstractFloat. Today an overflowing abstract expression produces an error. In the future if we used 128 bits or more, then that expression might not overflow. By not specifying a correct answer today, we can expand the precision of the type without breaking backward compatibility of working applications. By comparison, the Go language requires compilers to support constant evaluation well beyond 64 bit precision.

Further reading

• WGSL § 2.1 Shader Lifecycle
• WGSL § 7. Variables and Value Declarations
• Constants in the Go Blog. This is a really nice explanation of how Go treats constant values. I like the simplicity of treating constant values as being typeless as possible. Hopefully WGSL’s automatic conversions for abstract types gives much of that usability.
